CE PET Strap Making Machine Line 200kg/H

  • 1
  • 2

Brand Name : JIATUO

Model Number : JTPET-90

Certification : CE, ISO

Place of Origin : Shenzhen, China

MOQ : 1 Set

Price : Negotiable

Payment Terms : L/C, D/A, T/T, Western Union, MoneyGram

Supply Ability : 50 set/month

Delivery Time : 50~55 working days

Packaging Details : plastic film or other standard package for sea shipping

Product type : PET Strap Making Production Line

Raw material : PET Flakes Or 100% Recycled Material

PET Strap Width : 9-32mm

PET thickness Range : 0.6-12mm

Capacity : 200kg/h

Driven Type : Electric

Voltage : According To Customer's Factory

Motor : Siemens

Strap Color : Green/Pink/yellow/black

Application : Packaged Material

After-sales service provided : Video technical support, Online support

Warranty : 1 Year

Contact Now

PET Plastic Strap Making Machine With CE Certificate 100-200kg/H Capacity


PRODUCT DESCRIPTION

PET strap, also known as plastic steel band, which is used in place of steel on the world of a new environmentally friendly packaging materials, the development of new materials in recent years the cost of success and a substantial decline, have been widely used in the steel industry, chemical fiber industry, aluminum ingots, paper, brick kiln industry, screw industry, tobacco industry, electronics, textiles and wood, etc.; It is replaced by a new high-strength steel strapping, is the world’s most widely used for steel products with high strength.

PET Strap Production Line Machine List

NO. Item Specification
1 Power According to customer's factory voltage
2 Material PET raw material or 100% PET bottle flakes recycled
3 Capacity

PETJT90:200kg/h

PETJT100:250kg/h

PETJT125:350kg/h

4 Product size

Width:9-32mm

Thickness:0.6-12mm

6 Mid-height of extruder 7000mm
7 Installation power

PETJT90:200KW

PETJT100:250KW

PETJT125:300KW

8 Humidity <85%
9 Temperature 0-40 degree
10 Cooling tower capacity 30T/H or 50T/H
11 Installation Dimensions

PETJT90:45*2.0*7.0M

PETJT100:45*2.0*7.0M

PETJT125:60*3.0*8.0M

12 Product color Green/Black/Pink/Yellow
13 Factory dimension

35m*(3~6)m*(4~6)m

45m*(3~6)m*(4~6)m

If your factory not big enough,please contact with us,our engineer can according to your size to design

CE PET Strap Making Machine Line 200kg/H

Features of PET packing strap production line:

Feature 1:
• Raw material process and extrusion system.
• High performance crystallizing and drying system.
• Production can use 100% recycled material to obtain a high add value strapping band.
• Special designed PET screw, select of single or twin screw extruder.

Feature 2:
• Continuous back-flush screen changer operating technology (Europe technology).
• 100% full automatic self-cleaning screen changer.
• Double column 4 screen cavities.
• PLC control, change screen without production interrupted, not influence the production quality.

Feature 3:
• Special designed hot air stretching oven.
• Configured with heating unit and automatic temperature control system.
• High performance heat insulating layer.
• Better on strip stretching and heating, rapid heating, complete strip orientation stretching.

Feature 4:
• Embossing machine, Hydraulic control.
• Customization designed embossing roll pattern available.
• Configured with synchronous control system, adjust embossing roll vertical position and embossing strength accurately.

Feature 5:
• Heating oven for sizing
• Special designed technology, make sure the strip forming rapidly
• Prevent the strip from un-orientation after orientation, eliminate internal stress, make sure the quality and size accuracy of strip.

Feature 6:
• Strapping accumulator unit.
• Strap length and the winding tension can be controlled according to strap wind speed.
• Two times completely cooling strapping.
• Reduce strapping winding camber.

Feature 7:
• Servo control winder (Single position and double position optional).
• PLC control system, automatically adjust winding tension.
• Winding range from 5mm to 32mm.
• Servo motor controls winder displacement width and distance.
• Reduce the strap bending, make sure the strap is fit for automatic packaging equipment.

CE PET Strap Making Machine Line 200kg/H

CE PET Strap Making Machine Line 200kg/H
