Join Pack Handheld Strapping Machine Semi Automatic 12mm Width Adjustable

SHENZHEN JIATUO PLASTIC MACHINERY CO.,LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Join Pack Handheld Strapping Machine Semi Automatic 12mm Width Adjustable

  • 1
  • 2
  • 3

Brand Name : JOIN

Model Number : ES101

Certification : CE, ISO

Place of Origin : Shenzhen, China

MOQ : 1 Set

Price : Negotiable

Payment Terms : L/C, D/A, T/T, Western Union, MoneyGram

Supply Ability : 100 set/month

Delivery Time : 10~15working days

Packaging Details : plastic film or other standard package for sea shipping

Product name : Semi Automatic Strapping Machine

Cycle Time : 2 sec./strap

Tension Range : 3-40kgs

Strap Width : 5,6,9,12,15.5mm adjustable

Sealing Method : Heating element

Table Height : 750~830mm adjustable

Reel Inside Diameter : 200,230,280mm specified

Power Consumption : 0.4kw

Power Supply : 100/110/220/230/240V 50/60HZ, 1PH

Machine Dimension (L x W x H mm) : L845 x W430 x H750

Contact Now

Join Pack Semi Automatic Strapping Machine Strap Width Adjustable

PRODUCT DESCRIPTION
High performance equipped with digital indicator for electrical tension adjustment.

Low voltage DC motor driven, perform fast speed and wide tension range at low noise.
Available for narrow and thick strap.
Table height adjustable.
Legs dismountable for saving transportation and storage cost.

Cycle Time 2 sec./strap
Tension Range 3~40kgs
Strap Width 5,6,9,12,15.5mm adjustable
Sealing Method Heating element
Reel Inside Diameter 200,230,280mm specified
Power Supply 100/110/220/230/240V 50/60HZ, 1PH
Table Height 750~830mm adjustable
Power Consumption 0.4kw
Machine Dimension
(L x W x H mm)
L845 x W430 x H750
Machine Weight
(50%,100%,150%,200%)
65kgs

Join Pack Handheld Strapping Machine Semi Automatic 12mm Width Adjustable

Features of the semi-automatic strapping machine for PET strap:

High engineering standard and simple design

Easy operation, simple maintenance

Hinged stainless steel top plate

Mechanical outside tension control

Rigid castors with brake

Energy efficient, motor only runs as needed

Reliable P.C. Board control

Affordable for every budget

Offer maximum total value among competing brands

Proven quality

Join Pack Handheld Strapping Machine Semi Automatic 12mm Width Adjustable

How to use semi-automatic strapping machine:

1. Power switch: Turn ON to start the machine, and OFF to stop the machine.

2. Power indicator light (POWER): Turn on the power switch, the light is on.

3. Length adjustment for strap feeding (TIMER): Every one scale is about 500mm.For any adjustment that is required turn it in the clockwise direction. The length of the strap will then become longer.

4. Strap tension button (TENSION): Choose the tension degree of a strap according to the size of the package.

5. Cooling time adjustment (COOL TIME): Depending on the strap and the different tensile strength, adjust the cooling time, for better adhesion effects.

6. Safety door switch: If the top cover is opened, the machine will stop running automatically. (Please turn off the main power switch before opening top cover.

7. Manual feeding/Reset button (FEED/HOME): Press the FEED button to help feed the straps. The longer you press, the longer the strap will be. 8. If the machine is not at the home position, press the HOME button so that the machine will return to its home position.

Join Pack Handheld Strapping Machine Semi Automatic 12mm Width Adjustable
